ABOUT WORKCAT 40 CATAMARAN
Workcat 40 Catamaran is primary made for work on fish farms, including feeding and harvesting fish, maintaining nets, handling cages, and similar maritime tasks.
The boat is 12 meters long and 6,8 meters wide. It is powered by two Yanmar diesel engines, each with an output of 95,6 kW, achieving a speed of 8 knots at 90% load. The deck capacity is 13 tons, and it is equipped with a Palfinger deck crane with a winch that has a maximum lifting moment of 14,6 Tm, a working range of 420°, and a reach of 12,4 meters. The winch capacity is 2.500 kilograms.
The vessel can be configured for personal or tourist use. In such cases, the type of equipment, engine power, and the number of passengers on board (up to 50 for tourist purposes) can be adjusted. The construction and outfitting of the boat can be configured in the way that best suits the customer’s needs.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | VALUE |
|---|---|
| Maximum length | 12,00 m |
| Maximum width | 6,80 m |
| Maximum height | 1,98 m |
| Speed at 90% load | 8 kn |
| Weight of the empty equipped boat | 17.200 kg |
| Fuel tank | 2.000 l |
| Hydraulic oil reservoir | 240 l |
| Engines | 2x Yanmar 6CHE3 (2×95,6kW) |
| Crew | 1 |
| Number of passengers | 6 |
| Crane | Palfinger PK15500(M)-C HYBRID |
| Maximum lifting moment | 14,6 Tm |
| Operating range | 420° |
| Reach | 12.4 m |
| Winch capacity | 2.500 kg |
